信號發生器FG-7002C

韓國EZ.DIGITAL 信號發生器FG-7002C介紹

詳細介紹
Wide frequency range : 0.02Hz to 2MHz in 7 range 4-in-1 sweep, function & pulse generator frequency er Versatile waveforms : Sine, Triangle, Ramp, Pulse sawtooth DC output Built-in 6 digit internal external er display (Max. 50MHz) Internal external linear sweep control from 1 : 1 to 100 : 1 Low distortion factor less than 1% at 0.2Hz to 100kHz TTL CMOS leveled square wave output Variable DV offset control Variable symmetry to generate sawtooth pulse waveform Variable output level control with 20dB attenuator amplitude control 韓國EZ.DIGITAL 信號發生器FG-7002C技術參數
功能描述
Output waveform	Sine, Triangle, Square, Pulse sawtooth, Ramp, TTL, CMOS
Frequency range	0.02Hz～2MHz in the 7 ranges
Frequency accuracy	1
Input voltage	0 to 10V(DC + AC peak)
Frequency variable range	100 : 1 or more
DC offset	【10V(without load), 【5(with load)
Symmetrical variable range	10 : 1 to 1 : 10 or more
Distortion	less than 1%(0.2Hz ～ 100kHz)
Rise / fall time	less than 110ns
Linearity	less than 1% up to 100kHz less than 5% up to 2MHz
Output	TTL level
Rise/fall time	less than 25ns
Output	4V～15V 【 1V, continuously variable
Rise/fall time	less than 110ns (at Max. output level)
Width	1 : 1 to 100 : 1
Rate	20ms to 2s (50hz to 0.5Hz)
Internal sweep	linear
External sweep	by means of VCF input
Output voltage	20Vp-p (open circuit), 10Vp-p(into 50з)
Attenuator	-20dB
Impedance	50з 【 5%
Display	6 digit green LED(0.2Hz ～ 50MHz)
Accuracy	time base error 【 1 er
Input sensitivity	100mV on kHz range 300mV on MHz range
Max. input voltage	150Vrms at 1kHz
Operating environmen	0∩ ～ 35∩, 85% RH
Range for guaranteed	25∩【 5∩, 75% RH
Power requirement	AC 115 / 230V 【 10%, 50/60Hz
Power consumption	approx. 20W
Accessories	power cord, fuse, operation manual, BNC cable
物理特性
長度	260mm
寬度	255mm
高度	80mm
持有證書
	CE
