功率計4410A性能特點
美國鳥牌BIRD 功率計4410A
范圍：200kHz-2.3 GHz、2mW-10KW
Multipower, ±5% Reading Accuracy, Portable Wattmeter Temperature-compensated accurate CW FM power measurements from 200 kHz to 2.3 GHz 2 mW to 10 KW. Uses special 4410-series wide-range elements. Wide-range accuracy over a 37 dB dynamic range. Quick Change (QC) connectors to minimize the need for adaptors when making critical measurements.The Model 4410A uses the basic principles “l(fā)ook feel” of the Model 43
美國鳥牌BIRD功率計4410A詳細介紹
Multipower, ±5% Reading Accuracy,Portable Wattmeter
Temperature-compensated accurate CW FM power measurements from200 kHz to 2.3 GHz 2 mW to 10 KW.
Uses special 4410-series wide-range elements.
Wide-range accuracy over a 37 dB dynamic range.
Quick Change (QC) connectors to minimize the need for adaptorswhen making critical measurements.
The Model 4410A uses the basic principles “l(fā)ook feel” ofthe Model 43 but transforms it into a highly accurate high dynamicrange instrument. The mirrored-scale linear range meter has 2switchable ranges, 0-1 0-3. Power is read as a multiple of thevalue indicated by the pointer, the decimal point locationdepending upon the range switch position the factor printed onthe plug-in element. Power ranges covered by individual elementsare 2 mW to 10 W, 20 mW to 100 W, 200 mW to 1 KW 2 W to 10 KW,full scale. For most elements, accuracy is +/-5% anywhere above 20%of full scale. The circuitry operates from a stard 9V alkalinebattery.
Element Tables / Product Support Service
Accessories:
Quick Change Solderless Connectors - QC-Type "Quick ChangeSolderless" RF Connectors
Support Tools:
Calibration Procedure
Operation Manual
Product Specifications:
|
Accuracy: |
±5% of readingfor any reading above 20% of the Power Range selected for FM or CWsignals without AM. This accuracy is maintained for a full 37 dBdynamic rance with each 4410 Element (except No. 4410-1 200 kHz-535kHz which is accurate to ±10% of reading, 4410-15 1.0-1.8 GHz 4410-16 1.8-2.3 GHz wich are accurate to ±8% ofreading.) |
|
Ambient Temperature Range: |
Elements 4410-1through -8 -10 through -16 are temperature compensated forrated accuracy from 0° to 50° C (32° to 122°F) 4410-20 through-27 from 20° C to 30° C(68° to 86°F) |
|
Connector: |
QC Type (FemaleN normally supplied) |
|
Finish: |
Gray powdercoat |
|
FrequencyRange: |
200 kHz to 2.3GHz CW or FM |
|
Insertion VSWR: |
with NConnectors 1.25 max. to 2300 MHz |
|
Nominal Size: |
6 7/8" H x 51/8" W x 3 5/8" D, (175 mm x 130 mm x 92 mm) |
|
Over-Range Protection: |
To 120%ofnominal full scale (I.e. 12 W, 120 W, 1200 W, or 12,000 W). Nodamage or degradation to the unit will result, regardless of theRange Selector Switch position. |
|
PowerRange: |
2 mW to 10 W,20 mW to 100 W, 200 mW to 1 kW or 2 W to 10 kW full scale in onesingle Plug-in Element. Any Bird Series 4410-Element may beused. |
|
Weight: |
3lbs. (1.4kg) |
4410A型功率計探頭選型表
|
4410 SeriesElements |
|
Table 9 - Full Scale Power Frequency Ranges 0-10, 30, 100, 300 Milliwatts, 1, 3, 10Watts |
|
MHz |
30-50 |
50-88 |
88-108 |
- |
150-250 |
225-400 |
400-800 |
800-900 |
900-1000 |
|
Model |
4410-20 |
4410-21 |
4410-27 |
- |
4410-23 |
4410-24 |
4410-25 |
4410-26 |
4410-28 |
|
